Aluminum Glass Doors Manufacturer China Factory Price Frameless Pivot Swing
1. System Overview — Transparent Entry
The Aluminum Glass Door — frameless pivot, swing, and sliding glass entry systems — defines modern entrances with transparency and precision hardware. As a premier manufacturer in China, Richocean engineers glass doors with 6063-T6 frames, tempered safety glass, and premium pivots, at factory-direct prices.
2. Core Material Science — 6063-T6 Frames
The frame and pivot structure carries the full door weight. Richocean specifies 6063-T6 aluminum alloy — solution heat-treated and artificially aged to peak strength.
Door frames are precision-machined at ±0.1mm tolerance, with concealed gasket channels and reinforced corners for heavy glass panels.
3. Door Types — Pivot, Swing & Sliding
Richocean delivers three principal glass door types:
- Pivot doors: top and bottom pivots, smooth operation up to 300kg
- Swing doors: side hinges, standard commercial entry
- Sliding glass: top-hung rollers for automatic or manual operation
4. Pivot Hardware — Precision Bearings
The pivot system is the heart of a frameless glass door. Richocean specifies precision pivot hardware:
- Floor springs: hydraulic closing, adjustable speed 0°–15°
- Load capacity: 80–300kg per pivot set
- Durability: 500,000+ open/close cycles
5. Safety Glass & Fittings
Performance is delivered by tempered and laminated glass:
- Tempered glass: 10–12mm, 620°C heat treatment, EN 12150
- Patch fittings: SS316 stainless, concealed fixing
- Laminated option: SGP interlayer retains glass on impact
6. Performance Specification Table
| Parameter | Standard | Value |
|---|---|---|
| Glass Safety | EN 12150 | 10–12mm tempered |
| Pivot Durability | EN 1154 | 500,000 cycles |
| Door Weight | Pivot rating | 80–300kg |
| Air Infiltration | ASTM E283 | < 0.30 m³/h·m² |
| Forced Entry | ASTM F588 | Grade 30 passed |
7. Technical FAQ
Q: What is the maximum leaf size for a frameless glass door?
A: Typical maximum is 1,200mm wide × 2,600mm high with 12mm tempered glass; larger leaves require reinforced pivots and engineered frames.
Q: What is the difference between pivot and hinge doors?
A: Pivot doors rotate on top and bottom pins, supporting heavier glass; hinge doors swing from side-mounted hinges. Pivot suits frameless design.
Q: How does the floor spring work?
A: The floor spring is a hydraulic unit embedded in the slab that controls door speed and holds position; it returns the door to closed automatically.
8. China Market Ranking — Why Richocean is #1
Richocean ranks #1 in China for glass door export volume. The Foshan factory runs automated CNC machining and powder-coating lines with 80,000m² annual capacity, serving Southeast Asia, the Middle East, and North America. Factory-direct pricing runs 30–50 percent below Western distributors.
9. Illustrative Project Applications
Example A — Luxury Hotel (Illustrative)
240 frameless glass doors across a 5-star hotel lobby and guest floors; 12mm tempered leaves and floor springs met high-traffic requirements. Illustrative example values.
Example B — Corporate Showroom (Illustrative)
80 pivot glass doors for an automotive showroom; SS316 patch fittings delivered seamless transparency. Illustrative example values.
10. Price Analysis
- Door type: swing standard; pivot adds 20–35%
- Glass tier: standard clear base; low-iron +15–25%; laminated +35–50%
- Hardware tier: standard vs premium European pivots +25–40%
- Indicative range: $150–350/m² FOB Foshan
11. 360° Service & Founder Philosophy
Richocean’s 360 service covers CAD drawing support, structural calculations, installation video documentation, 10-year aluminum warranty, and 5-year hardware warranty. The founder’s philosophy — Passion Plus Extreme Requirements Equals Peace of Mind — means every millimeter of every frame must satisfy the strictest global standards.
12. Conclusion
The Aluminum Glass Door defines transparent entry. With 6063-T6 frames, precision pivots, and tempered safety glass, Richocean delivers this engineering from China at factory-direct prices.
